13-10-04-Butterfly Valve Lever Type

ITEM NO: SL-810

1. Material: PVC, CPVC, PP, PVDF
2. Size: 1½" - 8''; 63mm - 225mm ; DN50 - DN200
3. Standard: ANSI, DIN, JIS
4. Joint End: Flanges
5. Working Pressure: 150 PSI
6. Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
7. Valve body color : PVC(dark gray), CPVC(light gray), PP(light yellow)

ADVANTAGES

1. 1. Improved PP disc to enhance the performance
2. 2. Thickened body & seal to extend the service life
3. 3. Materials meet drinking water standard
4. 4. 100% pure virgin material, CaCO3 free (Chalk)
5. 5. UV resistant powder added
6. 6. Can be assembled with Pneumatic/Electtric Actuators
